Mini ploča (B) ze RPi CM 5, EEPROM And Encryption Chip

1 na zalihama

Šifra proizvoda: w30703 Kategorija: oprema Oznaka: lok z-10 Težina proizvoda: 59 g

Opis

Mini Base Board (B) / Mini-Computer designed for Raspberry Pi Compute Module 5 (NOT Included), Onboard EEPROM And Encryption Chip

SKU: 30703
Part No.: CM5-IO-BASE-B
Brand: Waveshare

Mini Base Board (B) / Mini-Computer designed for Raspberry Pi Compute Module 5 (NOT Included), Onboard EEPROM And Encryption Chip

CM5-IO-BASE-B

CM5 socket	suitable for all variants of Compute Module 5
Networking	Gigabit Ethernet RJ45 connector
Connector	M.2 M KEY (2230 / 2242)
Connector	Raspberry Pi 40PIN GPIO header
USB	USB 3.2 Gen1 Type-A × 2, USB 2.0 × 2 (6PIN 1mm FFC connector)
MIPI	4-lane MIPI interface × 2 (22pin 0.5mm FFC connector)
Video	HDMI port × 2 (including one port via FFC connector), supports dual 4K outputs
Storage	TF card slot for Compute Module 5 Lite (without eMMC) variants
Fan header	5V, 4PIN JST-SH PWM connector
Others	Onboard EEPROM and Encryption chip
Power input	DC 5V 5A
Dimensions	the base board: 85 × 56mm
Dimensions	with metal case: 90 × 68mm

standard CM5 socket and color-coded Raspberry Pi 40PIN GPIO header
suitable for Compute Module 5 Lite/eMMC series module

Mini Base Board (B) designed for CM 5, connecting with Compute Module 5

onboard multiple connectors, more convenient to use

Mini Base Board (B) designed for CM 5, onboard interfaces

Provides fast and secure symmetric authentication

Mini Base Board (B) designed for CM 5, onboard EEPROM and encryption chip

Mini Base Board (B) designed for CM 5, onboard components

CM5 socket
suitable for all variants of Compute Module 5
40PIN GPIO header
for connecting various HAT / HAT+ modules
Power input/Programming
5V / 5A power supply, or used for eMMC burning
Encryption chip (ATSHA204)
Supports fast and secure symmetric authentication
PSW Power button
Long press to force power off, short press to soft power off or on
STAT LED
Dual-color status LED
BOOT button
Press before powering on and release after powering on to enter the burning mode
Dual MIPI interfaces
for connecting DSI displays and CSI cameras
HDMI0 connector
HDMI0 port, supports 4K output
USB 3.2 Gen1 ports
2x USB 3.2 Gen1 high-speed ports, supports 5Gbps synchronous operation
RJ45 Gigabit Ethernet port
Supports 10M / 100M / 1000M network access

4PIN JST-SH PWM Fan header
for connecting cooling fan, 5V power supply
TF card slot
for connecting a TF card with pre-burnt image (Lite variant ONLY)
IO-VREF selection
CM5 IO logic level: 3.3V (default) or 1.8V
Other function pins
WIFI / BT hardware disable or write protection
HDMI1 FFC connector
HDMI1 port, supports 4K output, can be connected through an adapter
USB 2.0 FFC connector
can be connected through an adapter
RTC battery holder
Supports CR / ML1220 button cell
M.2 M KEY
Supports 2230/2242 NVMe Solid State Drives and booting Pi5 from solid state drive
I2C selection
switching I2C0 and I2C1 (by default) for the encryption chip and EEPROM
CAT24C32
EEPROM chip
