2,390 RSD (Sa PDV-om)
SIM7028 NB-IoT HAT za Raspberry Pi, Global Band NB-IoT Comm, male dimenzije, mala potrošnja
1 na zalihama
Opis
SKU: 25349
Part Number: SIM7028 NB-IoT HAT (EN)
Brand: Waveshare
Korisne infromacije: www.waveshare.com/wiki/SIM7028_NB-IoT_HAT
SIM7028 NB-IoT HAT For Raspberry Pi
Supports Global Band NB-IoT Communication, Small In Size, Low Power Consumption
Features At A Glance
The SIM7028 NB-IoT HAT is a small size, low-power, and powerful Raspberry Pi HAT with NB-IoT (Narrow-Band Internet of Things) function, supports global band and supports TCP, UDP, LWM2M, COAP, DTLS, DNS, NTP, PING, HTTP(S), MQTT(S), TLS/SSL, etc. It is designed for applications that need low delay, low power, and low throughput, also suitable for IoT applications such as meters, remote control, asset tracking, remote monitoring, remote healthcare, bicycle-sharing, and so on.
- Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards and Jetson Nano, etc.
- Supports TCP, UDP, LWM2M, COAP, DTLS, DNS, NTP, PING, HTTP(S), MQTT(S), TLS/SSL, etc.
- Onboard Type-C interface for software debugging
- Onboard UART control pins, for connecting with host boards like Arduino/STM32
- 1x LED indicators, easy to monitor the working status
- Onboard USB to UART chip, the UART communication pin can be configured via jumper
- Onboard nano SIM card slot, compatible with NB-IoT specific card
- Baudrate: 2400bps ~ 460900bps (115200bps by default)
- Control via AT commands (3GPP TS 27.007, 27.005, and SIMCOM enhanced AT Commands)
- Supports SIM application toolkit: SAT Class 3, GSM 11.11, USAT
- Comes with online development resources and manual (examples for Raspberry Pi/Jetson Nano/Arduino/ESP32)
Specifications
| COMMUNICATION PARAMETERS | |
|---|---|
| Band | B1/B2/B3/B4/B5/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B66/B70/B85 |
| Data rate | ≤159Kbps(UL) ≤127Kbps(DL) |
| OPERATING PARAMETERS | |
| Power supply | 5V |
| Logic level | 5V/3.3V (3.3V by default) |
| Overall current (idle mode) | 4mA |
| Single module current (VBAT=3.3V) | Idle mode: 2.8mA |
| PSM mode: 0.8uA | |
| DRX mode: 0.11mA@Idle(DRX=2.56s) | |
| eDRX mode: 0.018mA@Idle(eDRX=163.84s; PTW=25.6s) | |
Standard Raspberry Pi 40PIN GPIO
Compatible With Raspberry Pi Series Boards, Jetson Nano, Etc.
Connect to Raspberry Pi Zero
Connect to Raspberry Pi 4B
Connect to Jetson Orin
for reference only, the above control boards are NOT included
Global Band Support
Supports Communication Protocols Including TCP, UDP, LWM2M, COAP, DTLS, DNS, NTP, PING, HTTP(S), MQTT(S), TLS/SSL, Etc.
Application Example
Provides Multiple Networking Demos With Waveshare.Cloud, AWS IoT Core, And Aliyun IoT Support, Using The Lightweight MQTT Protocol To Achieve Data Visualization Services
Waveshare.Cloud Support
Provides Tutorial And Demo For Quick Start Of Smart IoT Solutions, With Large-Screen Data Visualization Display To Meet Various Application Scenarios
Pinout Definition
Product Show
Outline Dimensions
- PACKAGE CONTENT
Weight: 0.06 kg
- SIM7028 NB-IoT HAT x1
- GSM Antenna x1
- USB Type-A to Type-C cable x1
- 2×20PIN female header x1
- Standoffs pack x1
Dodatne informacije
| Težina | 77 g |
|---|
Deklaracija
| Šifra: w25349 |
| Naziv: SIM7028 NB-IoT HAT |
| Vrsta: Waveshare |
| Zemlja porekla: Kina |
| Zemlja uvoza: Kina |
| Uvoznik: MALINA 314 doo, Beograd |
| Telefon: 061-640-2013 |
