Dual Eth ploča za Raspberry Pi CM5, podržava 4G / 5G module, Dual 4K HDMI, Dual MIPI Interfejs, 40PIN GPIO, USB 3.2 Gen1, PoE podrška
Dual Eth ploča za Raspberry Pi CM5, podržava 4G / 5G module, Dual 4K HDMI, Dual MIPI Interfejs, 40PIN GPIO, USB 3.2 Gen1, PoE podrška - Slika 2
Dual Eth ploča za Raspberry Pi CM5, podržava 4G / 5G module, Dual 4K HDMI, Dual MIPI Interfejs, 40PIN GPIO, USB 3.2 Gen1, PoE podrška - Slika 3
Dual Eth ploča za Raspberry Pi CM5, podržava 4G / 5G module, Dual 4K HDMI, Dual MIPI Interfejs, 40PIN GPIO, USB 3.2 Gen1, PoE podrška - Slika 4
Dual Eth ploča za Raspberry Pi CM5, podržava 4G / 5G module, Dual 4K HDMI, Dual MIPI Interfejs, 40PIN GPIO, USB 3.2 Gen1, PoE podrška - Slika 5

6,390 RSD (Sa PDV-om)

Dual Eth ploča za Raspberry Pi CM5, podržava 4G / 5G module, Dual 4K HDMI, Dual MIPI Interfejs, 40PIN GPIO, USB 3.2 Gen1, PoE podrška

1 na zalihama

Šifra proizvoda: w32580 Kategorija: Oznaka: Težina proizvoda: 118 g

Opis

SKU: 32580
Part No.: CM5-DUAL-ETH-4G/5G-BASE
Brand: Waveshare

Korisne informacije: www.waveshare.com/wiki/CM5-DUAL-ETH-4G/5G-BASE

Dual Ethernet Base Board For Raspberry Pi CM5, Supports 4G / 5G module, Dual 4K Display Outputs and Dual MIPI Interfaces, Onboard 40PIN GPIO Header And Dual USB 3.2 Gen1 Ports, PoE Module Support

Dual Ethernet Base Board for CM5

Designed for Raspberry Pi Compute Module 5Dual Ethernet Base Board For Raspberry Pi CM5, front view

Specifications

CM5 socket Suitable for all variants of Compute Module 5
Networking 1000M Ethernet RJ45 port × 1
2500M Ethernet RJ45 port × 1
Connector Raspberry Pi 40PIN GPIO header
USB USB 3.2 Gen1 × 2
MIPI 4-lane MIPI interface × 2 (22PIN 0.5mm FFC connector)
Video HDMI port × 2, supports dual 4K display outputs
M.2 M.2 M KEY (PCIe Gen2/3 x 1)
M.2 (4G / 5G) M.2 M KEY, supports connecting 4G / 5G communication module
Storage TF card socket for Compute Module 5 Lite (without eMMC) variants
Fan Header 5V, 4PIN JST-SH PWM fan connector
Power Input 7V~36V wide voltage range DC jack, 5V 5A Type-C port
Dimensions the base board: 99.60 × 87.00 (mm)
the case: 104.80 × 90.00 × 29.70 (mm)

Connecting with Compute Module 5

standard CM5 socket and color-coded Raspberry Pi 40PIN GPIO header
suitable for Compute Module 5 Lite / eMMC series module

Dual Ethernet Base Board connecting with Compute Module 5

* for reference only, please refer to the package content for detailed part list

4G / 5G module compatibility

compatible with communication modules with M.2 B KEY interface

Dual Ethernet Base Board For Raspberry Pi CM5, Suitable for 4G/5G communication modules

* An additional communication module is required to enable 5G/4G/3G/2G cellular network function, recommended: SIM7600G-H-M.2, SIM8200EA-M2, and SIM8262E-M2.

Supports connecting to M.2 NVMe Drive

Faster reading/writing speed compared to the TF card slot of Raspberry Pi, greatly improving reading/writing efficiency of the system or files, Supports booting Pi5 from NVME Solid State Drive

Dual Ethernet Base Board For Raspberry Pi CM5, Supports M.2 NVMe Solid State Drive

* for reference only, please refer to the package content for detailed part list

Applicable M.2 drive sizes

Dual Ethernet Base Board For Raspberry Pi CM5, Suitable with M.2 Solid State Drive dimensions

NVMe Drive Slot Support

Dual Ethernet Base Board For Raspberry Pi CM5, Suitable with Solid State Drive Interface

* Only supports the NVMe Protocol Solid State Drives.

More rich interfaces

Features multiple interfaces including ETH / MIPI / HDMI / Micro SD / USB / M.2 B KEY / M KEY , for easy to use

Dual Ethernet Base Board For Raspberry Pi CM5, More rich interfaces

What’s On Board

Dual Ethernet 4G/5G Base Board designed for CM 5, onboard components

  1. CM5 socket
    suitable for all variants of Compute Module 5
  2. 40PIN GPIO header
    suitable for connecting to various HAT / HAT+ modules
  3. M.2 M key
    supports 2242 / 2230 NVMe Solid State Drives or AI modules
  4. Programming
    used for eMMC burning or USB OTG
  5. BOOT switch
    switch to ON: burning mode
    switch to OFF: system normal startup mode
  6. PSW power button
    Long press to force power off, short press to soft power off or on
  7. System indicators
  8. M.2 M key status indicators
  9. RTC battery holder
    supports CR / ML 1220 button cell
  10. Dual MIPI interfaces
    for connecting to DSI displays or CSI cameras
  11. DC power jack
    DC 5.5 2.1 jack, supports DC 7V ~ 36V power supply
  12. M.2 B key
    supports connecting 4G/5G communication module
  13. Dual USB 3.2 Gen1 ports
    USB 3.2 Gen1 Type-A ports, up to 5Gbps
  1. FAN header
    for connecting cooling fan, 5V, 4PIN JST-SH PWM fan connector
  2. M.2 M key status indicator
    keeps blinking when NVMe drive is reading / writing
  3. Dual HDMI ports
    supports dual 4K outputs
  4. PoE header
    for connecting PoE module, supports PoE power supply through 1000M Ethernet port using PoE switch
  5. 1000M Ethernet RJ45 port
    supports 10M / 100M / 1000M network connections
  6. 2500M Ethernet RJ45 port
    supports 10M / 100M / 1000M / 2500M network connections
  7. USB to 2500M Ethernet chip
  8. IO-VREF selection
    CM5 IO logic level: 3.3V (default) or 1.8V
  9. Other function pins
    Hardware disable function, write protection and chip address selection
  10. TF card slot
    for connecting a TF card with pre-burnt image (Lite variant ONLY)
  11. NANO SIM card slot
  12. USB3.0 HUB

Outline dimensions

Dual Ethernet Base Board designed for CM 5, outline dimensions

About Compute Module 5 (nije u pakovanju)

Raspberry Pi Compute module 5, front view

Newly upgraded, more powerful
  • Upgraded processor BCM2712, quad-core Cortex-A76 64-bit SoC, more powerful performance
  • More options for RAM (2GB / 4GB / 8GB / 16GB)
  • More options for eMMC Flash (0GB (Lite) / 8GB / 16GB / 32GB / 64GB)
  • Faster eMMC Flash storage, up to 200 Mbps data rate
  • Optional for certified radio module, supports either PCB trace antenna or external antenna, more suitable for industrial applications
  • Adopts B to B connectors, most compatible with Compute Module 4
  • Onboard Gigabit Ethernet PHY supporting IEEE1588, suitable for network applications
  • Onboard PCIe Gen 2 x1 interface, allows connecting more useful modules

Package content:

Weight: 0.084 kg

CM5-DUAL-ETH-4G/5G-BASE

  1. CM5-DUAL-ETH-4G/5G-BASE x1
  2. Screws pack x1
1CM5-DUAL-ETH-4G/5G-BASE
2Screws pack
