37,990 RSD (Sa PDV-om)
23.8 inča FHD Monitor, touch, metalno kućište, HDMI, integracija sa Raspberry Pi
1 na zalihama
Opis
Oglas je za 23.8″
SKU: 34080
Part No.: 23.8inch FHD Monitor (EU)
Brand: Waveshare
Korisne informacije: docs.waveshare.com/23.8inch_FHD_Monitor
23.8 inch Capacitive Touch Monitor
High Resolution | Multi-touch | Full Color
23.8inch FHD Monitor
Device & System Support
Supports Ubuntu / Kali / WIN10 IoT, single point touch, driver free
Supports Retropie, driver free
* the mounting holes inside the case are only compatible with Raspberry Pi 4B and Raspberry Pi 5
Connection Examples
Working with Raspberry Pi 5
Working with Raspberry Pi 4
Working with Raspberry Pi CM5 / CM4
*for using with CM5 / CM4, an extra adapter board is required: CM5-to-Pi5-Adapter, CM4-to-Pi4-Adapter
Working with Jetson Orin
Working with mini PC
*for reference only, the above controller boards or hosts are NOT included
Configurable Display Orientation
1920 × 1080 resolution (H × V),
Change the software config for portrait display
Wide viewing angle IPS display panel
Excellent Display Performance, Wide viewing angle up to 178°
Supports FHD resolution
1920 × 1080 resolution, clearer display
Capacitive 10-point touch
- up to 10-point touch, depending on the operating system
- up to 6H hardness toughened glass panel
- Optical Bonding, display well and dustproof
Dual-track Speaker
Ferrite Hi-Fi Speaker, Stereo Sound Effect, Wider Sound Range, Better Sound Quality
*for reference only, the Raspberry Pi is NOT included
Reserved airflow vents
All-In-One Design
The Raspberry Pi Can Be Installed Inside To Make It As An All-In-One Mini-Computer
*for reference only, the Raspberry Pi is NOT included
Installation Methods
Supports multiple mounting options to meet the requirements of different application scenarios
Flush Mount
Wall Mount
Desktop Mount
Suspended Mount
* for reference only, the mounting bracket is NOT included, please choose the mounting method according to your needs
Interface Introduction
Application Scenarios
Suitable for commercial displays, smart device control, and human-machine interaction
Commercial Display
Smart Guide
Smart Home Terminal
IoT
DIY Device
AI Interactive Display
Product show
Outline dimensions
23.8inch FHD Monitor
Package content:
Weight: 6.77 kg
23.8inch FHD Monitor
- 23.8inch FHD Monitor x1
- 12V 5A Power supply x1
- USB Type-A male port to Type-C male port cable ~15cm x1
- USB Type-A male port to Type-C male port cable ~1m x1
- HDMI flat cable ~1m x1
- Cleaning cloth x1
- Screws pack x1
Dodatne informacije
| Težina | 5300 g |
|---|
Deklaracija
| Šifra: w34080 |
| Naziv: 23.8inch FHD Monitor |
| Vrsta: Waveshare |
| Zemlja porekla: Kina |
| Zemlja uvoza: Kina |
| Uvoznik: MALINA 314 doo, Beograd |
| Telefon: 061-640-2013 |
